2pt 3pt 4pt Thickness with 600W Laser Cutting Machine TSD-LC600-1218

2pt 3pt 4pt Thickness with 600W Laser Cutting Machine TSD-LC600-1218

Technical Specifications:

Machine model No.	TSD-LC600-1618
Laser Type	TSD Laser CO2 direct-current stimulated glass laser
Cutting area	width 1600mm x length1800mm
Machine weight	2000kgs
Driving motor	Panasonic servo motor
Cutting depth	15mm-18mm-20mm plywood
Cutting precision	±0.05mm
USB port connection	Yes
Operating temperature	0-45°C
Mould knife thickness	0.45mm, 0.71mm,1.07mm…etc. controllable
Cutting speed 400W	25-30meters/hour 18-20mm plywood
Protective gas	Dry and oil-free air
Power supply	single-phase electricity 220V±5% 50Hz 10A
Numerical control panel	LCD screen, light-touched key-press
Software supported	Auto CAD
Graphic format support	Auto CAD files.
EMS memory	attached 32MB memory, can work under off-line condition
Laser tube guarantee	guarantee 8 months,6000 hours life span for laser tube
Assistant equipment	air dryer, industrial chiller, exhaust fan, computer system
Recommend spare parts	laser tube, lens, mirror
H.S Code	8456110090

Machine Feature:

1. High effective and optimized exhaust system to reduce smoke during working, and keep a healthy environment.

2.Laser power Devices: China brand Hongyuan.

3.Fixed laser path, ensure the stability of the optical path.

4.Laser cutting head coming with auto touching following system, adapt to the jagged materials.

5.High temperature heat treatment working table and large gantry milling processing.

6.Stable machine design, high strength of machine bed, long-year working.

7.Low consumption of voltage about 5-7 kilowatt per hour.
