TSD-RD730 Auto Rotary Steel Rule Blade Bender Machine for Rotary Die Making
Technical Parameters:
Bending rule thickness(mm) | 4pt (1.42mm) |
Bending rule diameter(mm) | 250-600mm |
Bending rule height(mm) | 25-27mm |
Standard functions | Bending, cutting, perforation, bridge |
Cutting methods | Auto flat cutting |
Bridge size | Bridge width 10/13mm, height 10-18mm |
Perforation size | Perforation width 2-13mm, height 0.5-6mm |
Mold selection | Customized |
Operation system | Windows 10 |
Optimal pattern format | DXF, DWG, AI, CF2 |
Air supply | 0.6-0.8Mpa |
Power supply | 1P 220V, 20A, 50/60Hz |
Machine total power | 3KW |
Machine weight | 830KGS |
Overall dimension | 1460*1500*1840mm(L*W*H) |
HS CODE | 8462219000 |
Functions and usage:
1. It supports to work on both flat and rotary steel rule, easy to exchange.
2. Various diameter of rotary steel rule, 250-600mm.
3. Automatically matched with different diameters while changing shortly.
4. Servo motor control system, which makes more efficiently and accurately.
5. Innovative design with stable machine body, which can be used for long years.
