CO2 Laser Cutting Machine for UV Coated Plywood Cutting for Die Making
Technical Specifications:
Machine model No. | TSD-LC400-1218 |
Laser Type | TSD Laser CO2 direct-current stimulated glass laser |
Cutting area | width 1200mm x length 1800mm |
Machine weight | 2000kgs |
Driving motor | Servo motor |
Cutting depth | 15mm-18mm-20mm plywood |
Cutting precision | ±0.05mm |
USB port connection | Yes |
Operating temperature | 0-45°C |
Mould knife thickness | 0.45mm, 0.71mm,1.07mm…etc. controllable |
Cutting speed 400W | 25-30meters/hour 18-20mm plywood |
Protective gas | Dry and oil-free air |
Power supply | single-phase electricity 220V±5% 50Hz 10A |
Numerical control panel | LCD screen, light-touched key-press |
Software supported | Auto CAD |
Graphic format support | Auto CAD files. |
EMS memory | attached 32MB memory, can work under off-line condition |
Laser tube guarantee | guarantee 8 months,6000 hours life span for laser tube |
Assistant equipment | air dryer, industrial chiller, exhaust fan, computer system |
Recommend spare parts | laser tube, lens, mirror |
H.S Code | 8456110090 |
1.Fixed laser path, ensure stable optical path.
2. Laser head can be automatically adapted to jagged material, ensuring uniform cutting seam.
3. Large gantry milling and high-temperature heat treatment working table, can be used for long years without deformation.
4. Off-line control system, it's easy to set up cutting parameters on the LCD screen.
5. Sealed laser path and clean environment offer a long-time lifespan for the lens.
6. High effective and optimized exhaust system to reduce smoke during working, and keep a healthy environment.
7. Motor System: Panasonic servo motor to guarantee high precision cutting.
8. Drive System: HIWIN Linear guide rail + ball screw to guarantee high precision cutting and table moving.
